ICE-PEL S series is a small-type full-automatic dry ice pellet production equipment. It has the compact structure and excellent performance,which can produce dry ice particles in different sizes by changing different molds.
It can be used with dry ice washing machines or used as a stand-alone production machine；
PLC control system, production parameters can be set easily. (Exclude Model ICE-PEL 15)；
The produced dry ice is high-density and high-purity, and the consumption rate is relatively reduced；
It can produce food-grade dry ice pellets；
It can produce dry ice particles in different sizes by changing different molds；
Totally enclosed design, using high-quality stainless-steel plate as the outer body,which is neat and generous in appearance, and the open frame design is easy to maintain；
The core components adopt world-famous brands to ensure the reliable running for 24hours a day and 7 days a week in a row；
Build-in designed hydraulic pump station and dry ice molding module reduce the floor area of equipment and avoid the influence of dust in production；
Compact structure with small floor space, easy to move,which is the best choice for small & medium-sized workshops；
| الطراز | ICE-PEL S15 | ICE-PEL S20 | ICE-PEL S30 | ICE-PEL S60 |
|---|---|---|---|---|
| Dry Ice Output | 10-15 KG/H | 15-20 KG/H | 25-30 KG/H | 50-60 KG/H |
| CO2 Conversion Rate | 35-45% | 35-45% | 35-45% | 40-45% |
| Hydraulic Oil | 64HM | 64HM | 64HM | 64HM |
| Oil Tank Capacity | 50L | 50L | 80L | 80L |
| Motor Power | 1.5KW | 1.5KW | 2.5KW | 4KW |
| Inlet Pressure | 16-20Bar | 16-20Bar | 16-20Bar | 16-20Bar |
| الأبعاد | 470x820x350mm | 470x820x350mm | 1100x430x660mm | 1100x650x660mm |
| الوزن | 113KG | 116KG | 180KG | 260KG |
| الفولتية | 220V/50Hz, 1Ph | 220V/50Hz, 1Ph | 380V/50Hz, 3Ph+N+PE | 380V/50Hz, 3Ph+N+PE |
Standard: Deice main body (1unit), cryogenic flexible hose (1piece), 3mm dry ice mold (1piece)
Optional: Hydraulic oil, food-grade hydraulic oil, optional molds, mold quick-changing tool, spare kit.
العبوة: علبة القشرة القياسية الدولية
كفالة: سنة واحدة
Dry ice is a commonly used industrial consumable and a necessary refrigeration consumable for cold-chain transportation. It can be built to produce and sell dry ice in areas where tire rubber vulcanization plants are concentrated and where fresh agricultural products are produced.
Since dry ice is not easy to store and transport, it is recommended that the sales range of dry ice be within 100km or the transportation time should not exceed 12 hours.
The dry ice production process is simple and convenient to manage. The sales volume is stable. Once a fixed source of customers is developed, he will usually be purchased for a long time.
ما هو الثلج الجاف؟
الجليد الجاف هو الحالة الصلبة لثاني أكسيد الكربون (CO₂) التي تتشكل عند درجة حرارة -79 درجة مئوية.
يوجد ثاني أكسيد الكربون بشكل طبيعي على الأرض في صورة غاز. وهو غير سام ولا طعم له، وغالبًا ما يُستخدم لتزويد المشروبات بالغازات لإضفاء طعم منعش عليها وإطالة مدة صلاحيتها. كما يُستخدم الثلج الجاف في صناعة الأغذية لتبريد الأطعمة أو في مجال الخدمات الصحية.
